Welded steel bar panels are made with the bearing bars automatically welded at the contact point with the cross bars. A kind of square mesh or rectangular opening metal structure. Under a combination of high heat and pressure, the carbon steel bars are fused together to form a permanent joint. The cross bars provide a high degree of rigidity, yet retain a smooth flat panel surface for free and easy walking.
Bar welded grate panels are the most popular at many flooring panels and tread plates for its strength, low cost and easy of installation. The grating universally is used in most general industrial plants as well as commercial buildings. It is also ideal for use as mezzanine decking since it supports the same loads as comparable solid flooring. More than that, its cost saving openness maximizes the circulation of air, light, heat, water and sound, while promoting cleanliness. And, where insurance codes permit, additional sprinklers can often be eliminated. Standard panels are available in widths of 2', 3' or 4'.
Materials applied: mild steel, stainless steel 304 or 316.
Surface treatment: galvanizing, bitumen dipped, painted, untreated.
Top surface: plain, flattened, raised.
Welded steel bar grating is a rugged, one-piece constructed panel.
We supply steel bar welded mesh for grating, also named welded mesh grating.
Galvanized steel mesh grating is made by carbon or mild steel of certain sizes through the processing of grooving,lock pressure,welding, finishing and other treatment. Industrial bar gratings can be actually made from copper, aluminum and other materials, while galvanized steel grating is the mostly used one due to its economic cost and good property.
Galvanized steel grating with robust design and spanning ablities,is very strong and safe for the support of floors and elevated walkway.it can be used for ceiling ,interior decoration,decoration,platform aisle,ventilation windows,(wells).advertising plaque and other construction.
Please specify the following when ordering our gratings:
1.Center to center distance of the grating bars;
2. Panel width;
3. Panel length;
4. Bar width
Typical center to center distances of the gratings:
30mm Gratings: This is the strongest industrial steel gratings. Widely used in metallurgy, drainage, stair treads, chemical plants, walkway, etc.
40mm Gratings: This is the most economic type widely used for light bearing surface, walkway, stair gratings, etc.
60mm Gratings: This kind is special for mine industry gratings.
Welded Mesh Panels for Grating, Fencing or Construction Reinforcing
Welded Mesh Panel is a flat sheet welded structure made of superior quality steel wire or steel bar. It has flat even surface and firm structure. Varieties according to uses: Fencing Panels, Steel Grating Panels, Welded Mesh Panels for Construction and other uses. The flat mesh panels can be fabricated into a large variety of wire products (welded wire forms): Containers, cages, carts, shelving, racks and boxes.
Reinforcing Steel Mesh Sheet Assortments according to processing and materials:
Galvanized Welded Mesh Panel
Electro galvanized welded wire mesh panel
Hot Dipped Galvanized welded mesh panel
PVC Coated Welded Wire Mesh panel
Stainless steel welded wire mesh panel
Features : Smooth and trim mesh surface, solid and uniform structure and superior integral performance, it won't loosen even subject to local cutting or pressure, It has the characteristics of corrosion-resisting and oxidation-resisting.
Use: Welded mesh panel is extensively used in industry and agriculture construction,transportation and mining for all such purposes as poultry houses, egg baskets,runway enclosures, floor heating draining rack, fruit drying screen, fence, fruit drying screen,fence and other industries . |
Specification of Welded Steel Wire Mesh:
| Welded Wire Mesh |
| Opening |
Wire Diameter<BWG> |
| In inch |
In metric unit(mm) |
| 1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
| 3/8" x 3/8" |
10.6mm x 10.6mm |
19,20,21,22 |
| 1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
| 3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
| 1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
| 1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
| 2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request. |
| Galvanized Fencing Mesh |
| Opening |
Wire Diameter<BWG> |
| In inch |
In metric unit(mm) |
| 2" x 3" |
50mm x 75mm |
2.0mm,2.5mm,1.65mm |
| 3" x 3" |
75mm x 75mm |
2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
| 2" x 4" |
50mm x 100mm |
2.11mm,2.5mm |
| 4" x 4" |
100mm x 100mm |
2.0mm,2.5mm |
Technical Note:
1, Standard roll length: 30m;width: 0.5m to 1.8m
2, Special sizes available at request
3, Packing: in waterproof paper in rolls. Custom packing available at request. |
| PVC Coated Welded Mesh |
| Opening |
Wire Diameter<BWG> |
| In inch |
In metric unit(mm) |
| 1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21 |
| 3/4" x 3/4" |
19mm x 19mm |
16,17,18,19,20,21 |
| 1" x 1" |
25.4mm x 25.4mm |
15,16,17,18,19,20 |
Technical Note:
1, Standard roll length: 30m;width: 0.5m to 1.8m
2, Special sizes available at request
3, Packing: in waterproof paper in rolls. Custom packing |
Packing of welded wire mesh: Water-proof paper then shrinked plastic bag or as your requirement. |
